ALLOYWORKS 3 Row All Aluminum Radiator 16" Fan Shroud Relay for 1988-1995 Toyota Pickup 4Runner SR5 3.0L V6 Engines Crossflow Radiators, OEM CC50, 23 1/2" H x 23 1/2" W

THIS LISTING INCLUDING THE RADIATOR AND SHROUD AND ONE 16" FAN AND Thermostat Kits! Radiator Size: Row: 3 Row Core Material: Full Aluminum Radiator Flow: Cross Flow Core and Tank: All Aluminum Core size(in) approx: 18 3/4" x 20 3/4" x 2 Overall size(in) approx: 23 1/2" x 23 1/2" Top Hose Location & Size: Passenger 1 3/8" Bottom Hose Location & Size: Driver 1 3/8" CNC machined filler neck and cap Aircraft 5057 grade aluminum and with raw aluminum finish OEM style brass petcock drain. Vehicle Fitment: For Toyota 4Runner 3.0L 1988 1989 1990 1991 1992 1993 1994 1995 For Toyota Pickup 3.0L 1988 1989 1990 1991 1992 1993 1994 1995 FANS: Maximum Fan CFM: 1730 cfm Fan Diameter (in): 16.050” Thickness (in): 2.500” Number of Blades: 10 blades Maximum Fan RPM: 2,250 rpm Blade Material: Plastic Amp Draw: 12.70 amps Includes the Mounting Tabs for an Easy Zip Tie Installation Thermostat Kit: Universal fit for any automotive vehicle and electric fan. Activates by grounding electric fans at preset temperature. 180'F turn-on temperature, 165'F turn-off temperature. 3/8" NPT thread-in brass probe w/ 1/2" NPT adapter included. Probe typically threads into radiator, water outlet or manifold.

• ◆ [Vehicle Fitment] OEM 1190 CU1190 1190 RAD1190 DPI1190, Radiator Replacement For Toyota 4Runner 3.0L 1988 1989 1990 1991 1992 1993 1994 1995; For Toyota Pickup 3.0L 1988 1989 1990 1991 1992 1993 1994 1995;
• ◆ [Dimensions] Core size(in) approx: 18 3/4" x 20 3/4" x 2“; Overall size(in) approx: 23 1/2" x 23 1/2"; Top Hose Location & Size: Passenger 1 3/8"; Bottom Hose Location & Size: Driver 1 3/8";
• ◆ [Premium Quality] Constructed with Aircraft AA5052 aluminum, this radiator is 100% welded and features brazed core technology with no epoxy. The high-quality aluminum core makes it a direct fit and built to last long. Before delivery, each radiator undergoes five checks in the production process and is pressure tested to ensure no leakage.
• ◆ [Density Core] Cooling rows are spaced 3/8" apart, giving you 25% more rows within the core than other aluminum radiators sold on Amazon. 14-16 cooling fins per inch, giving you approximately 1500 more cooling fins than other aluminum radiators. It provides 30% more cooling capacity than a standard radiator.
• ◆ [No Leaking Worries] All radiator have to go through 5 checks in the whole process.100% leaking and pressure tested. Thickened packing(either carton or wooden box), foam with shock absorption.
